Fender Mustang Prewire Premium PIO Tone Caps

Free USA Shipping

This kit is for: Fender Mustang, 2 Single coil pickups. This kit has single volume control, single tone control with 3 way toggle switch located in lower section of the pick guard under neck pickup (see control layout picture to compare to your guitar). Note: This kit does not have the extra slide switches that some early model Mustangs had.

What’s In The Kit:

• 50’s wiring
• Bourns Pro Audio High Grade 250K Short Shaft Audio Taper pots with Brass Bushings 1 dress washer 2 nuts.
• Includes set of pot sleeves for use with knobs that have set screw to secure.
• Paper-In-Oil (PIO) K42Y-2 0.033uf Centralab Tone Cap.
• Switchcraft or Centralab (brand depends on availability) prewired 3-way toggle r-angle switch black tip.
• Gavitt 22 awg vintage cloth push back and braided wire with insulation thru out.
• Assembled template hard board.  Note the template does not get installed.
• 50’s Wiring diagram and easy to read installation instructions.
• Every kit goes thru our Performance and Accuracy Testing before being shipped out. Our kits work.

Pot Value Option:

• For Mustang with humbucker pickups we can substitute 500K pots in you prefer. Just add a note when purchased.


Cavity size requirements:

• Minimum cavity depth at switch location is 13/16 inch / 20.64 mm
• Switch length (in cavity) requirement for R Angle is a full 2 inches.

NOTES:

• Each harness is custom built after purchase . Lead time to build kit before shipping is 5 to 12 business days depending on my back log of kits. In stock quantity means I have the parts to build that quantity of kits.
